Swedish tennis court
Project location: Sweden
Project Name: steel structure tennis court
The project is located in Sweden. The customer purchased a batch of steel structures for the construction of a steel structure tennis court. The main steel and main beam are q355b steel, welded H-shaped steel beam and stainless steel to SA2 Grade 5, 3 layers of antirust paint, the color is gray;
The secondary steel frame adopts Q235B, s235jr, SS400, astma36 and stainless steel to SA2 Level 5. 3 layers of antirust paint, with paint thickness of 120 μ m. The color of angle steel and round steel is gray.
The purlin adopts Q235B galvanized steel, the high-strength bolt with nut adopts M20, grade 10.9s, the ordinary bolt with nut adopts M12 and M16, the nut adopts M12 and M20, the anchor bolt with nut adopts M24 * 1000mm, and the color is silver;
The plate is made of rock wool board, and the roof panel is made of rock wool sound insulation board 950mm wide and 150mm thick. One side is customized black with a density of 80kg / m ²， 0.4mm thick metal plate. The wall panel adopts 950mm wide and 150mm thick rock wool sandwich plate. One side custom color ral7016, horizontal installation, density 80kg / M ²， 0.4mm thick metal plate; There are other accessories, etc.
Our technical engineers strictly control the appearance, size, material specifications and other details of the tennis court, communicate with customers and finally determine all products of the project. After the customer's confirmation, we produced and delivered the goods. After receiving the goods, the customer sent us pictures and fed back that the product quality was very good. The color, specification and model were the same as those determined in the original communication. He was very satisfied with this cooperation. At present, it is being installed and affirmed the one-stop service of Canglong group.
